Technical parameters of the OR19
|
Product number |
FTTH-OR19 |
|
Received wavelength |
1100~1600nm&1550nm |
|
Input optical power |
0dBm~-10dBm(Analog)&0dBm~-15dBm(Digital) |
|
Light reflection loss |
＞45 dB |
|
Optical connector form |
SC/APC&SC/PC |
|
Frequency Range |
47~1006 MHz |
|
In-band flatness |
±1dB@47~ 1006 MHz |
|
RF output reflection |
≥16dB@ 47~550MHz;≥14dB@550~1006 MHz |
|
Output level |
≥80dBuV(AGC:@-3~-12dBm) |
|
RF output impedance |
75Ω |
|
AGC range |
（-3~-12）dBm |
|
Carrier to Noise Ratio (Note 1) |
≥51dB |
|
CTB (Note 1) |
≥65dB |
|
CSO (Note 1) |
≥62dB |
|
Host voltage |
DC5V |
|
Adapter voltage |
AC110V or AC220V or customized |
|
Infeed voltage |
DC5V |
|
Operating temperature |
-20℃ ~+45℃ |
|
Power consumption |
＜2W |
