| Gigabit Ehernet Transceiver Information | ||
| Transceiver form factor | Description | |
| Transceiver Type | QSFP28 | |
| Transmission speed | 100GE | |
| Center wavelength (nm) | 850 | |
| Standards compliance | 100GBase-eSR4 (non-standard) | |
| Connector type | MPO/PC (8-strand or 12-strand, type B, female connector) | |
| Applicable cable and maximum transmission distance | Multimode fiber (OM3): 200 m
Multimode fiber (OM4): 300 m |
|
| Transmit power (dBm) | -8.4 to +2.4 | |
| Maximum receiver sensitivity (dBm) | -9.2 | |
| Overload power (dBm) | 2.4 | |
| Extinction ratio (dB) | 2 | |
| Operating temperature | 0°C to 70°C (32°F to 158°F) | |
| Part number | 0231PSH | |
