| 10Gigabit Ehernet Transceiver Information | ||
| Comon information: | ||
| Transceiver form factor | SFP+ | |
| Transmission speed | 10GE | |
| Center wavelength (nm) | 1310 | |
| Standards compliance | 10GBASE-LRM | |
| Connector type | LC | |
| Applicable cable and maximum transmission distance | Multimode fiber (with modal bandwidth of 400 MHz*km and diameter of 50 μm): 0.1 km
Multimode fiber (with modal bandwidth of 500 MHz*km and diameter of 62.5 μm): 0.22 km Multimode fiber (OM1, OM2, OM3): 0.22 km |
|
| Transmit power (dBm) | -6.5 to +0.5 | |
| Maximum receiver sensitivity (dBm) | -6.5 | |
| Overload power (dBm) | 1.5 | |
| Extinction ratio (dB) | 3.5 | |
| Operating temperature | 0°C to 70°C (32°F to 158°F) | |
