| 10Gigabit Ehernet Transceiver Information | ||
| Comon information: | ||
| Transceiver form factor | SFP+ | |
| Transmission speed | 10GE | |
| Center wavelength (nm) | 850 | |
| Standards compliance | 10GBASE-SR | |
| Connector type | LC | |
| Applicable cable and maximum transmission distance | Multimode fiber (with modal bandwidth of 160 MHz*km and diameter of 62.5 μm): 0.026 km
Multimode fiber (OM1): 0.033 km Multimode fiber (OM2): 0.082 km Multimode fiber (OM3): 0.3 km Multimode fiber (OM4): 0.4 km |
|
| Transmit power (dBm) | -7.3 to -1.0 | |
| Maximum receiver sensitivity (dBm) | -11.1 | |
| Overload power (dBm) | -1.0 | |
| Extinction ratio (dB) | 3.0 | |
| Operating temperature | 0°C to 70°C (32°F to 158°F) | |
