| 40G Transceiver Information | ||
| Comon information: | ||
| Transceiver Type | 40GBASE_SR_QSFP+ | |
| Connector Type | MPO | |
| Wavelength (nm) | 850 | |
| Transfer Distance (m) | 100 (OM1) | |
| Digital Diagnostic Monitoring | Yes | |
| Vendor Name | Huawei | |
| Vendor Part Number | 02310NHR | |
| Diagnostic information: | ||
| Temperature (°C) | 24.00 | |
| Temp High Threshold (°C) | 80.00 | |
| Temp Low Threshold (°C) | -10.00 | |
| Voltage (V) | 3.35 | |
| Volt High Threshold (V) | 3.46 | |
| Volt Low Threshold (V) | 3.13 | |
| Bias Current (mA) | 5.83 / 5.83 (Lane0 / Lane1) | |
| 5.83 / 5.83 (Lane2 / Lane3) | ||
| Bias High Threshold (V) | 12.00 | |
| Bias Low Threshold (V) | 0.50 | |
| RX Power (dBM) | -40.00 / -40.00 (Lane0 / Lane1) | |
| -40.00 / -40.00 (Lane2 / Lane3) | ||
| RX Power High Warning (dBM) | 0.49 | |
| RX Power Low Warning (dBM) | -9.50 | |
| RX Power High Threshold (dBM) | 3.49 | |
| RX Power Low Threshold (dBM) | -12.50 | |
| TX Power (dBM) | -1.69 / -1.69 (Lane0 / Lane1) | |
| -1.55 / -1.44 (Lane2 / Lane3) | ||
| TX Power High Warning (dBM) | 0.49 | |
| TX Power Low Warning (dBM) | -7.59 | |
| TX Power High Threshold (dBM) | 3.49 | |
| TX Power Low Threshold (dBM) | -10.59 | |
