| Gigabit Ehernet Transceiver Information | ||
| Comon information: | ||
| Transceiver Type | 1000 BASE_LX_SFP | |
| Connector Type | LC | |
| Wavelength (nm) | 1310 | |
| Transfer Distance (m) | 40000 (9um) | |
| Digital Diagnostic Monitoring | Yes | |
| Vendor Name | Huawei | |
| Diagnostic information: | ||
| Temperature (°C) | 25.44 | |
| Temp High Threshold (°C) | 80.00 | |
| Temp Low Threshold (°C) | -10.00 | |
| Voltage (V) | 3.34 | |
| Volt High Threshold (V) | 3.60 | |
| Volt Low Threshold (V) | 3.00 | |
| Bias Current (mA) | 5.39 | |
| Bias High Threshold (V) | 85.00 | |
| Bias Low Threshold (V) | 0.00 | |
| RX Power (dBM) | -39.98 | |
| RX Power High Threshold (dBM) | -3.00 | |
| RX Power Low Threshold (dBM) | -23.00 | |
| TX Power (dBM) | -2.21 | |
| TX Power High Threshold (dBM) | 0.74 | |
| TX Power Low Threshold (dBM) | -5.25 | |
