Item |
Unit |
Parameter |
|
|
OpticalParameter |
Wavelength |
(nm) |
CATV:1550nm PON:1310/1490nm XGSPON: 1270nm/1577nm |
|
|
Responsibility |
(A/W) |
≥0.9 |
|
|
Optical input power |
(dBm) |
+2~-10 |
|
|
Return loss |
(dB) |
≥55 |
|
|
Optical Connector |
|
CATV:SC/APC PON:SC/APC or SC/PC |
|
RF parameter |
Bandwidth |
(MHz) |
45 ~ 1003 |
|
|
Output Level |
(dBμV) |
≥65dBuv (Pin＝0dBm) |
|
|
RF output impedance |
(Ω) |
75 |
|
|
RF Output port |
|
1 |
|
|
RF Output port type |
|
Metric or British |
|
Digital signal link index |
MER |
(dB) |
≥36 (Pin＝0dBm) |
|
|
BER |
(dB) |
<1.0E-9 (Pin＝0dBm) |
|
Working environment and specifications |
Working temperature |
(℃) |
-5 ~ +50 |
|
|
Storage temperature |
(℃) |
-40 ~ 85 |
|
|
Working humidity |
(%) |
5 ~ 95 |
|
|
size |
（mm） |
108×103×26mm |
