Name: ZTE SCTM Control Card
Brand: Guangzhou Mifan Electronic Technology Co., Ltd
SKU: MF0041
Price: 230.00 USD
Availability: InStock
Rating: 5 (1 reviews)

No.MF0041

ZTE ZXA10 SCTM switching and control board integrated with 4-port 10G SFP+ uplink for C300/C350

Packing Box Specifications

48*33*7cm

Gross Weight

2.5kgs

Condition

Original new

Lead Time

1-3 working days

Warranty

12 months

Shipping Method

DHL, UPS, FedEx, Sea/Air/Railway Freight

Payment Method

PayPal, Bank Transfer(T/T), LC, Western Union, UnionPay, Alipay

Get Price/Help

Bulk Quote View Quote List

Description

ZTE SCTM Overview

The ZTE SCTM is a main control board for ZTE's ZXA10 C300/C350 Optical Line Terminal (OLT) platform, featuring four 10GE uplink ports, high-density GPON/EPON capabilities, robust traffic management (H-QoS, DBA), advanced security (AES128 encryption), Optical Laser Supervising (OLS), and support for Type B/C protection, enabling large-capacity, high-performance, and reliable broadband access for triple-play services with easy migration to next-gen PONs.

Product Features

High-Speed Uplinks: Equipped with four 10GE SFP+ ports for high-bandwidth backhaul and integration.
Broad PON Support: Compatible with GPON (G.984.x, G.987.x) and XG-PON1 standards, supporting various transceiver power classes (B+, C+, N1, N2a).
Advanced Traffic Management: Includes SR-DBA, NSR-DBA, H-QoS, and 1024 schedulers for efficient bandwidth allocation.
Enhanced Reliability: Supports Type B and Type C protection for link redundancy and OLS for laser monitoring.
Security: Features AES128 encryption and Single Copy Broadcast (SCB) for secure data transmission.
Control & Management: Full G.984.4 OMCI stack and out-of-band network management (NM) interface.

Application Scenarios

A French national telecom operator deployed ZTE SCTM cards with ZXA10 C350 OLTs for urban core-network FTTH/FTTB deployments (downtowns, tech parks). Boasting 2.56Tbps switching capacity, 4x10GE uplinks, and a 256K MAC table, it meets high-density demands for 4K streaming, enterprise cloud access, and 5G backhaul.
Priced at ~$2,800–$3,500/unit, it optimized TCO with low power consumption and seamless compatibility with GPON/XG-PON service boards. Supporting 1:128 splitting and 1588v2 sync, it served 5,000+ households and 200+ SMEs across 4 major cities. Post-deployment, network uptime hit 99.95%, with scalable design enabling future 25G/50G PON upgrades to align with the operator’s digital infrastructure expansion goals.

Downloadable resources

ZTE SCTM Board Datasheet

Technical Specifications

ZTE SCTM Board Datasheet
Performance	2.56 Tbit/s
Vadid Slot	ZXA10 C300 slot 10/11 ZXA10 C350 slot 6/7
Interface	• 1 out-of-band NM interface • 1 serial interface • 1 SD card interface • 4 10GE uplink interfaces • 1 mirroring interface
Function	• Provides one out-of-band NM interface, one debugging interface, one SD card interface. • Provides 4 SFP+ 10GE optical uplink interfaces (can be configured to SFP GE interfaces) • Support load balance work mode. • Works with the power card PRWH and the fan control card FCWD.
Power Consumption (W)	Static: 95, maximum: 120, typical: 110
Dimensions	395.5 mm × 25 mm × 225 mm
Weight	1.420 kg

FAQ

Q: What is ZTE SCTM?
A: ZTE SCTM is a high-performance service interface card designed for ZXA10 series OLTs, focusing on providing stable data transmission and service expansion capabilities for telecom networks.

Q: Which ZTE OLT models are compatible with SCTM?
A: It is seamlessly compatible with ZTE ZXA10 C300, C320, and C350 OLTs, adapting to mainstream chassis configurations for flexible deployment.

Q: What is the warranty period for ZTE SCTM?
A: It comes with a 12-month warranty covering manufacturing defects, supported by MF-Telecom’s professional after-sales service.

Q: What precautions are there for daily maintenance?
A: Regularly monitor the operating temperature (0°C–45°C), check for loose card connections, back up system configurations, and upgrade firmware per ZTE’s official guidelines.

Q: Is technical support available globally for SCTM?
A: Yes, MF-Telecom provides global technical support for genuine ZTE SCTM, including installation guidance and fault troubleshooting.
