- High Performance: 480 Gbps switching capacity; 32,000 MAC address table.Network Convergence: Supports GPON, EPON, and XG-PON1 (with relevant line cards); Future-proof hardware/software architecture for smooth upgrades.
- Reliability & Synchronization: Precise time/clock synchronization (Synchronous Ethernet, 1588v2) for mobile backhaul; Robust design for high-traffic networks, minimizing downtime.
- Connectivity & Scalability: Provides flexible uplink options (e.g., 4x 10GE, 2x 10GE + 2x GE); High-density subscriber support via compatible line cards (e.g., 16-port GPON).
- Energy Efficiency (Green Communication): Low power consumption design; Features Automatic Laser Shutdown (ALS) and board dormant modes; Complies with RoHS and other environmental standards.
- Integration: Seamlessly integrates into the ZXA10 C300/C350 OLT chassis.
Application Scenarios
A Spanish regional telecom operator deployed ZTE SCXM control & switch cards with ZXA10 C300 OLTs for suburban FTTH expansion. The SCXM’s 480 Gbps switching capacity and 32 K MAC table efficiently serve 2,000+ households, supporting 4K streaming and remote work needs. It seamlessly integrates with GPON service boards, enabling 1:64 splitting for wide coverage. With low power consumption and stable non-blocking switching, the card maintained 99.85% network uptime, optimizing TCO while meeting growing suburban bandwidth demands.
2. Small & Medium Enterprise (SME) Network in Canada
A Canadian IT service provider adopted ZTE SCXM cards in ZXA10 C300 OLTs to build fiber networks for 50+ SMEs. The SCXM’s reliable system control and 480 Gbps capacity handle multi-service traffic (data, video conferencing). Compatible with enterprise-grade line cards, it ensures secure and low-latency connectivity. Its plug-and-play design simplified deployment, and 24/7 stable operation (99.9% uptime) met SMEs’ business continuity requirements, with room for future user scale expansion.
Downloadable resources
Technical Specifications
| ZTE SCXM Board Datasheet |
| Switching Capacity |
480 Gbps |
| Vadid Slot |
ZXA10 C300 slot 10/11 |
| Interface |
• 1 out-of-band NM interface
• 1 serial interfac
• 1 SD card interface
• 1 mirroring interface |
| Function |
• Provides one out-of-band NM interface, one debugging interface, one SD card interface.
• Support active standby 1:1 work mode. |
| Power Consumption (W) |
Static: 50, maximum: 70, typical: 60 |
| Dimensions |
395.5 mm × 25 mm × 225 mm |
| Weight |
1.132 kg |
FAQ
Q: What is ZTE SCXM?
A: ZTE SCXM is a dedicated control & switch card for ZXA10 C300 OLT. It provides 480 Gbps switching capacity, 32 K MAC table, and enables non-blocking switching of line cards for multi-service transmission.
Q: Which OLT model is SCXM compatible with?
A: It is exclusively designed for ZTE ZXA10 C300/C350 OLT, ensuring seamless integration with the platform’s hardware and software.
Q: What is the warranty period for ZTE SCXM?
A: It comes with a 12-month warranty covering manufacturing defects, supported by MF-Telecom’s professional after-sales service.
Q: Is technical support available globally for SCXM?
A: Yes, MF-Telecom provides global technical support for genuine ZTE SCXM, including installation guidance and fault troubleshooting.
Q: What precautions are there for daily maintenance?
A: Keep operating temperature 0°C–40°C, regularly check card connections, back up configurations, and upgrade firmware per ZTE’s official guidelines.
