| Item | Parameters |
| Basic Information | |
| Module name | SFP-1000BaseT |
| Part Number | 02314171 |
| Model | SFP-1000BaseT |
| Form factor | SFP |
| Application standard | 1000BASE-T |
| Connector type | RJ45 |
| Optical fiber type | - |
| Digital diagnostic monitoring (DDM) | Not supported |
| Transmission rate [bit/s] | 10 Mbit/s |
| 100 Mbit/s | |
| 1 Gbit/s | |
| Target transmission distance [km] | Ethernet cable: 0.1 km |
| Transmitter Optical Characteristics | |
| Center wavelength [nm] | - |
| Maximum Tx optical power [dBm] | - |
| Minimum Tx optical power [dBm] | - |
| Minimum extinction ratio [dB] | - |
| Receiver Optical Characteristics | |
| Rx sensitivity [dBm] | - |
| Overload power [dBm] | - |
