Provides thirty-six 10M/100M/1000M Ethernet electrical ports and twelve 100M/1000M Ethernet optical ports for data transmission and line-rate switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot Swap
The EH1D2T36SEA0 is hot swappable.
Ports on the EH1D2T36SEA0
Optical port attributes (optical module)
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For details about optical modules supported by the EH1D2T36SEA0 and their attributes, see FE SFP/eSFP Optical Modules, GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Optical port attributes (copper module)
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP copper module used.
For details on the copper modules supported by the cards and attributes of the copper modules, see GE SFP Copper Modules (10 Mbit/s, 100 Mbit/s and 1000 Mbit/s rates).
Standards compliance
IEEE 802.3ab
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
10/100/1000BASE-T electrical port attributes
Attribute
Description
Connector type
RJ45
Standards compliance
IEEE 802.3ab
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the EH1D2T36SEA0
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 2.50 kg (5.51 lb)
Maximum power consumption: 62 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
EH1D2T36SEA0 FAQ
Q1: What are the core functions of this service board? How are its versatility and high reliability demonstrated?
A1: It contains 36 pure RJ45 Ethernet ports, supports 10G/1G dual-rate adaptive switching, and offers universal high-reliability forwarding. It is compatible with various types of pure Ethernet port terminals and service scenarios, with a bit error rate ≤10⁻¹² and low power consumption ≤165W, making it the preferred choice for large-scale pure Ethernet port access.
Q2: Compared to a regular 36-port 10GE Ethernet port board, what are its core advantages?
A2: The advantages are high-density slot saving, dual-rate compatibility with new and old terminals, high reliability and low bit error rate, and green low power consumption. It also addresses the three major pain points of pure Ethernet port scenarios: complex deployment, insufficient compatibility, and excessive power consumption.
Q3: Does it require a specific network cable? Which core protocols does it support?
A3: Compatible with Cat6a/Cat7 standard network cables (supports 10G transmission) and Cat5e/Cat6 network cables (supports 1G transmission); supports IPv4/IPv6 dual-stack, LACP, and VRRP, meeting the high reliability requirements of the access layer.
Q4: How to determine if this service board needs to be deployed? Is the installation complex?
A4: Deployment is recommended for medium-sized networks requiring 25-36 pure electrical port 10G terminals and pursuing high-density deployment; supports hot-swapping, installation requires no professional tools, ports automatically identify speed, plug and play.
