Provides two 100GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Ports on the ET1D2C02FEE0
Attribute
Description
Connector type
CFP
Optical port attributes
Depend on the 40GE CFP Optical Modules and 100GE CFP Optical Modules used
Applicable cable
CFP optical module and LC optical fiber
CFP optical module and MPO optical fiber (MPO-MPO, MPO-2*MPO, or MPO-10*DLC optical fiber)
Specifications of the ET1D2C02FEE0
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 4.20 kg (9.26 lb)
Maximum power consumption: 339 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to 158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2C02FEE0 FAQ
Q1: Which switches is this service board compatible with? Does it support hot-swapping?
A1: Dedicated compatibility with Huawei S9306/S9310/S9312 and E-series (S9306E/S9312E); supports hot-swapping, allowing online installation/replacement without interrupting core network operation.
Q2: What are the core performance parameters? What are the advantages compared to the 40G service board?
A2: Two 100GE optical ports (QSFP28), 100Gbps per port; advantages include a 2.5x speed increase, higher bandwidth per slot, support for dual-stack and link aggregation, suitable for ultra-high-speed backbone scenarios.
Q3: Does it require a specific optical module? What core functions does it support?
A3: Compatible with Huawei standard QSFP28 100G optical modules, selectable based on transmission distance; supports IPv4/IPv6 dual-stack, link aggregation, QoS, and flow control, meeting the high reliability requirements of backbone networks.
Q4: How do I determine if I need to deploy this 100GE service board? Is the installation complicated?
A4: Deployment is recommended when the enterprise's core network/data center backbone bandwidth is saturated, ultra-high-speed data transmission is required, or cross-regional leased line upgrades are needed. Installation requires no special tools; simply insert it into the corresponding S9300 slot for automatic recognition—plug and play.
