Provides four 10GE optical ports for data transmission and line-rate switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The ET1D2X04XEA0 is hot swappable.
Ports on the ET1D2X04XEA0
Attribute
Description
Connector type
XFP
Optical port attributes
Depend on the XFP optical module used.
For details about the optical modules supported by the ET1D2X04XEA0 and their attributes, see 10GE XFP Optical Modules, 10GE-CWDM XFP Optical Modules, and 10GE-DWDM XFP Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the ET1D2X04XEA0
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 2.16 kg (4.76 lb)
Maximum power consumption: 64 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2X04XEA0 FAQ
Q1: What are the core functions of this service board? What is its power consumption?
A1: It contains four 10GE SFP+ ports, supports distributed stable forwarding and link aggregation; low power consumption ≤70W, supports hot-swapping, and is suitable for ultra-small and micro-sized scenarios.
Q2: Compared with a regular 4-port 10G board, what are its core advantages?
A2: The advantages are low power consumption (suitable for civilian power supply), stable forwarding, simplified adaptation, and better fit the cost and usage needs of ultra-small and micro-sized scenarios.
Q3: Does it require a specific optical module? What civilian power supply scenarios is it suitable for?
A3: It is compatible with Huawei standard SFP+ 10G optical modules; suitable for civilian socket power supply scenarios with up to four terminals and a power supply ≤75W (such as small shops and remote network points).
Q4: How do I determine if this service board needs to be deployed? Is the installation complex?
A4: This deployment is recommended when a micro-network requires 4 10 Gigabit ports and can only provide low-power civilian power; it supports hot-swapping, and installation requires no professional tools, it is plug and play.
