Provides four 10GE optical ports for data transmission and line-rate switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The ET1D2X04XEC1 is hot swappable.
Ports on the ET1D2X04XEC1
Attribute
Description
Connector type
XFP
Optical port attributes
Depend on the XFP optical module used.
For details about the optical modules supported by the ET1D2X04XEC1 and their attributes, see 10GE XFP Optical Modules, 10GE-CWDM XFP Optical Modules, and 10GE-DWDM XFP Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the ET1D2X04XEC1
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 2.28 kg (5.03 lb)
Maximum power consumption: 75 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2X04XEC1 FAQ
Q1: What are the core functions of this service board? What is its power consumption?
A1: It contains four 10GE SFP+ ports, supports distributed forwarding and link aggregation; low power consumption ≤75W, supports hot-swapping, and is suitable for small and micro-sized scenarios.
Q2: What are its core advantages compared to a regular 4-port 10GbE board?
A2: The advantages are low power consumption (suitable for power-constrained scenarios), stable forwarding, simplified adaptation, and better fit the cost and usage needs of small and micro-sized scenarios.
Q3: Does it require a specific optical module? What scenarios is it suitable for?
A3: It is compatible with Huawei standard SFP+ 10G optical modules; suitable for small and micro-sized branches or micro-data centers with up to four terminals and limited power supply.
Q4: How do I determine if this service board needs to be deployed? Is the installation complex?
A4: It is recommended for deployment when a small and micro-sized network requires four 10GbE ports and prioritizes low power consumption and easy maintenance; it supports hot-swapping, and installation requires no professional tools—it's plug-and-play.
