Provides forty-eight 1000M/10G BASE-X ports for data access and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The ET1D2X48SEC0 is hot swappable.
Ports on th ET1D2X48SEC0
Optical port attributes (GE optical module)
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used. For the SFP optical modules supported by the ET1D2X48SEC0 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Optical port attributes (10GE optical module, high-speed cable or SFP+ optical cable)
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ - SFP+ high-speed cable (1 m, 3 m, 5 m, 10 m), QSFP+ - 4*SFP+ high-speed cable (1 m, 3 m, 5 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the ET1D2X48SEC0 and their attributes, see 10GE SFP+ Optical Modules, 10GE-CWDM SFP+ Optical Modules and 10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the ET1D2X48SEC0
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 3.42 kg (7.54 lb)
Maximum power consumption: 300 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2X48SEC0 FAQ
Q1: What are the core functions of this service board? Does it support adaptive speed?
A1: It contains 48 SFP+ ports, supports 1Gbps/10Gbps dual-mode adaptive speed; it features distributed forwarding and hot-swapping capabilities, adapting to massive multi-rate terminal access.
Q2: What are its core advantages compared to ordinary access boards?
A2: The advantages are its high-density 48-port design, 1G/10G dual-mode adaptation, distributed forwarding, higher single-slot access capacity, stronger adaptability, and no need to deploy multiple boards.
Q3: Does it require specific optical modules? What core functions does it support?
A3: It is compatible with Huawei standard SFP/SFP+ optical modules; it supports IPv4/IPv6 dual-stack, link aggregation, QoS, and flow control, meeting the reliability requirements of high-density access.
Q4: How do I determine if this service board needs to be deployed? Is the installation complex?
A4: This deployment is recommended when the data center/core network needs to connect 30+ multi-rate terminals and slot resources are limited; it supports hot-swapping, and installation requires no professional tools, it is plug and play.
