Provides data packet processing and traffic management on 12 100GE optical ports, which can be split into a maximum of 12 40GE optical ports, 48 25GE optical ports, or 48 10GE optical ports.
Maximum port density
If all LPUs are CE-L12CQ-FD cards:
The CE12804/CE12804S chassis provides a maximum of 48 100GE ports.
The CE12808/CE12808S chassis provides a maximum of 96 100GE ports.
The CE12812 chassis provides a maximum of 144 100GE ports.
The CE12816 chassis provides a maximum of 192 100GE ports.
100GE port
Supports QSFP28 optical modules. A 100GE port can be used as a 40GE port or split into four 25GE or 10GE ports. Therefore, a CE-L12CQ-FD card can provide a maximum port density of 12x40GE, 48x25GE, or 48x10GE.
Technical specifications
Item
CE-L12CQ-FD
CPU
Eight-core, 1.5 GHz clock speed
DDR3
Standard 4 GB
Flash
Standard 128 MB
Physical specifications
Dimensions (W x D x H): 433.0 mm x 530.8 mm x 45.7 mm (17.05 in. x 20.90 in. x 1.80 in.)
Weight: 5.8 kg (12.79 lb)
Typical power consumption: 234 W
Maximum power consumption: 323 W
Typical heat dissipation: 800 BTU/hour
Max. heat dissipation: 1104 BTU/hour
Environment parameters
Operating temperature: 0°C to 40°C (32°F to 104°F)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Operating relative humidity: 5% RH to 85% RH (noncondensing)
Certification
Safety standards compliance
EMC standards compliance
Environmental standards compliance
CE-L12CQ-FD FAQ
Q1: Which Huawei switch models does the CE-L12CQ-FD support? How compatible is it?
A1: It mainly supports mid-to-high-end Huawei switches such as the CE8800 series (CE8850, CE8860, CE8861) and CE7800 series (CE7850, CE7855). It is fully compatible in both hardware and software, with 100% compatibility and no additional debugging required.
Q2: Are the 12 100GE ports sufficient for the core needs of enterprise branch offices? Is multi-card expansion complicated?
A2: A single card can meet the basic core/aggregation needs of small to medium-sized branch offices; multi-card expansion simply requires plugging the card into the switch slot without additional configuration, making operation simple and efficient.
Q3: What is the difference between the CE-L12CQ-FD and the 16-port CE-L16CQ-FD? How should I choose?
A3: The CE-L12CQ-FD focuses on small and medium-sized businesses with high cost-effectiveness, while the CE-L16CQ-FD has higher capacity. When there are no large-scale expansion plans for enterprise branches or small data centers, the CE-L12CQ-FD offers better cost-effectiveness and more controllable costs.
