Huawei CE128000 Series Switch CE-SFU12G Switch Fabric Unit.
Functions and features
Function and Feature
Description
Line-speed data switching
Six CE-SFU12Gs constitute the switching core of the data plane and provide high-speed Serdes channels for LPUs.
Reliability
The CE-SFU12G uses a single-stage multi-plane switch fabric to expand the switching capacity. The system has six switching planes, which work in load balancing and redundancy mode to ensure nonstop service data switching.
Technical specifications
Item
Description
Reliability
Load balancing and redundancy design
Physical specifications
Dimensions (W x D x H):648.2 mm x 271.4 mm x 40.1 mm (25.52 in. x 10.69 in. x 1.58 in.)
Weight: 5.9 kg (13.01 lb)
Typical power consumption: 283 W
Maximum power consumption: 416 W
Typical heat dissipation: 967 BTU/hour
Maximum heat dissipation: 1421 BTU/hour
Environment parameters
Operating temperature: 0°C to 40°C (32°F to 104°F)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Operating relative humidity: 5% RH to 85% RH (noncondensing)
Certification
Safety standards compliance
EMC standards compliance
Environmental standards compliance
CE-SFU12G FAQ
Q1: Which Huawei switch models does the CE-SFU12G switching board support? How compatible is it?
A1: It mainly supports Huawei CE5800 series basic models (CE5810, CE5850 basic models) and CE6800 series entry-level models (CE6810, CE6850 entry-level models), etc., with full hardware and software compatibility and 100% compatibility.
Q2: Is a single 12Tbps bandwidth sufficient for the core needs of small and micro enterprises? What is the performance after dual-board expansion?
A2: A single 12Tbps bandwidth can meet the basic core needs of small and micro enterprises; after dual-board expansion, the total capacity is ≥24Tbps, with non-blocking forwarding, fully supporting traffic scheduling after business growth.
Q: What is the difference between the CE-SFU12G and the higher-specification CE-SFU16G? Do small and micro enterprises need to upgrade?
A: The CE-SFU12G focuses on basic bandwidth and extreme cost-effectiveness, while the CE-SFU16G has higher capacity; for small and micro enterprises without large-scale expansion plans, the CE-SFU12G can meet their daily business needs without the need for additional paid upgrades.
