Port for inputting and outputting 400GE/200GE/100GE/40GE optical signals
40GE QSFP+ optical modules
100GE QSFP28 optical modules
200GE QSFP56 optical modules
400GE QSFP-DD optical modules
QSFP+ to QSFP+ AOC cable
QSFP28 to QSFP28 AOC cable
QSFP-DD to QSFP-DD AOC cable
QSFP56 to QSFP56 AOC cable
QSFP-DD to 2*QSFP56 AOC cable
QSFP-DD to QSFP-DD high-speed cable
QSFP-DD to 2*QSFP56 high-speed cable
Technical specifications of the CEL36DQHG-P
Item
Specification
Dimensions without packaging (H x W x D) [mm (in.)]
55.4 mm x 433.0 mm x 523.2 mm (2.18 in. x 17.05 in. x 20.60 in.)
Dimensions with packaging (H x W x D) [mm (in.)]
285 mm x 650 mm x 860 mm (11.22 in. x 25.59 in. x 33.86 in.)
Weight without packaging [kg (lb)]
10.5 kg (23.15 lb)
Weight with packaging [kg (lb)]
16.8 kg (37.04 lb)
Typical power consumption [W]
1337 W
Typical heat dissipation [BTU/hour]
4562 BTU/hour
Static power consumption [W]
734 W
Static heat dissipation [BTU/hour]
2504 BTU/hour
Maximum power consumption [W]
1725 W
Maximum heat dissipation [BTU/hour]
5886 BTU/hour
CPU
4-core, 1.4 GHz clock speed
Memory
Standard 8 GB
CEL36DQHG-P FAQ
Q1: Which Huawei switch models does the CEL36DQHG-P support? How compatible is it?
A1: It mainly supports Huawei CE12800 series mid-to-high-end switches (such as CE12808/CE12812), CE8800 series high-end switches (such as CE8868-4C-EI), and some models of the CE9800 series. The interfaces and slots are fully matched, with 100% compatibility; simply plug it in and it's ready to use.
Q2: Do the 36 400G ports support 100G optical modules? Is it compatible with existing optical module assets?
A2: It supports 400G/100G rate auto-negotiation and can directly use existing 100G QSFP28 optical modules without additional purchase, effectively ensuring compatibility with existing optical module assets and reducing upgrade costs.
Q3: How are the power consumption and heat dissipation performance of this interface card? Are additional cooling measures required?
A3: It adopts a low-power design, with single-card power consumption controlled at a low level compared to similar products in the industry. It is also compatible with the switch's built-in cooling system, so no additional cooling measures are needed, and it will not put extra pressure on the switch's heat dissipation.
