The LST7G48SX6E0 provides the following functions:
Communicates with the MPU and works under the control of the MPU.
Searches for routes and destination addresses of data packets for forwarding.
Forwards data packets.
Function
Description
Basic functions
Provides forty-eight GE optical ports for data access and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For optical modules supported by the LST7G48SX6E0 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LST7G48SX6E0
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.2 kg (7.05 lb)
Maximum power consumption: 147 W
LST7G48SX6E0 FAQ
Q1: What are the core advantages of this service board? In what ways is it "enhanced"?
A1: The core advantages are enhanced stable forwarding, high cost-effectiveness with 48 ports, dual-rate compatibility, and low power consumption. The "enhanced" aspect is reflected in optimized anti-interference design, reduced bit error rate, and stable forwarding performance, balancing cost and reliability.
Q2: Which optical modules does it support? Can it directly connect to existing 1G equipment?
A2: It supports Huawei standard SFP+ 10G optical modules (SR/LR/ER) and SFP 1G optical modules; dual-rate adaptive, it can directly connect to existing 1G equipment without additional converter configuration.
Q3: How does its energy consumption and reliability compare to other high-performance 48-port 10G boards of the same level?
A3: Total power consumption ≤190W, 28% more energy-efficient than comparable products; bit error rate as low as 10⁻¹³, superior reliability, suitable for critical business scenarios in small to medium-sized networks.
Q4: Is it suitable for enterprises with limited budgets that require stable transmission? Is installation complicated?
A4: Very suitable; cost-effective and highly stable, supports hot-swapping and plug-and-play, installation requires no professional skills, automatically identifies the speed after plugging into the switch, and configuration is simple.
