Provides eight 100GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Port of the ET1D2C08HX2H
Attribute
Description
Connector type
QSFP28
Optical port attributes
Depend on the QSFP28 high-speed cable (1 m, 3 m, 5 m), QSFP+ high-speed cable (1 m, 3 m, 5 m), 40GE QSFP+ Optical Modules, 100GE QSFP28 Optical Modules (QSFP-100G-ER4 not supported), or QSFP+ or QSFP28 AOC cable used.
Applicable cable
QSFP+ optical module and LC optical fiber
QSFP+ optical module and MPO optical fiber (MPO to MPO or MPO to 4*DLC optical fiber)
QSFP+ high-speed copper cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP+ AOC cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP28 optical module and LC optical fiber
QSFP28 optical module and MPO optical fiber (MPO to MPO)
QSFP28 high-speed copper cable
QSFP28 AOC cable
Specifications of the ET1D2C08HX2H
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.5 kg
Maximum power consumption: 289 W
ET1D2C08HX2H FAQ
Q1: What are the core advantages of this service board? What practical value does the high density of 8 ports bring?
A1: The core advantages are high density of 8 ports, 40G/10G dual-rate compatibility, low power consumption, and high stability. High density significantly saves switch slots, and the dual-rate design reduces upgrade costs, adapting to the needs of large-scale 40G networking.
Q2: Which optical modules does it support? Can it directly connect to existing 10G legacy equipment?
A2: It supports Huawei standard QSFP+ 40G optical modules (SR4/LR4/ER4) and QSFP+ 10G optical modules; dual-rate adaptive design allows direct connection to existing 10G equipment without additional converter configuration.
Q3: How does its power consumption and forwarding performance compare to other 8-port 40G boards of the same level? A3: Total power consumption ≤160W, 30% more energy efficient than comparable products; forwarding capacity ≥640Gbps, supports full-load concurrent forwarding on 8 ports, no performance bottlenecks, suitable for high-load scenarios.
Q4: What network scale scenarios is it suitable for? Is installation complex?
A4: Suitable for 40G large-scale access scenarios such as large data centers, medium-to-large campuses, and carrier city aggregation; supports hot-swapping, installation without downtime, automatic speed recognition after insertion into the switch, simple configuration.
