Provides forty-eight GE electrical ports for data transmission and line-rate switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The ET1D2G48TEC0 is hot swappable.
Ports on the ET1D2G48TEC0
Attribute
Description
Connector type
RJ45
Standards compliance
IEEE 802.3ab
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the ET1D2G48TEC0
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 2.66 kg (5.86 lb)
Maximum power consumption: 68 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2G48TEC0 FAQ
Q1: What are the core functions of this service board? How does it balance enhanced high concurrency and hybrid optical/electrical connectivity?
A1: It includes 48 10GE hybrid optical/electrical ports (SFP+/RJ45 auto-negotiation), supporting 10G/1G dual rates and enhanced high-concurrency forwarding (≥9500PPS); it integrates optical and electrical connections to adapt to mixed terminals, with 48 ports providing ultra-high density for large-scale access, and low power consumption ≤208W, suitable for high-load scenarios.
Q2: What are the core advantages compared to a regular 48-port hybrid optical/electrical board?
A2: The advantages are enhanced high concurrency (no peak bottleneck), intelligent resource scheduling, and green low power consumption. It also addresses the three major pain points of complex deployment, insufficient concurrency, and excessive power consumption in hybrid interface scenarios, making it more suitable for high-requirement core deployments.
Q3: Does it require specific optical modules/network cables? Which core protocols does it support?
A3: Compatible with Huawei standard SFP+ optical modules and Cat6a/Cat7 network cables; supports IPv4/IPv6 dual-stack, QoS, LACP, and VRRP, meeting the high reliability and redundancy requirements of the core aggregation layer.
Q4: How to determine if this service board needs to be deployed? Is the installation complex?
A4: Deployment is recommended when large networks require 40+ mixed interface terminal accesses and there are high load peak scenarios; supports hot-swapping, installation requires no professional tools, and the port automatically identifies optical/electrical modes and speeds, making it plug-and-play.
