The ET1D2S08SX1E provides the following functions:
Communicates with the MPU and works under the control of the MPU.
Searches for routes and destination addresses of data packets for forwarding.
Forwards data packets.
Function
Description
Basic functions
Provides eight 10GBASE-X ports and eight 10/100/1000M combo ports for data access and line-rate switching.
Forwarding speed
88 Gbit/s
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The ET1D2S08SX1E is hot swappable.
Ports on the ET1D2S08SX1E
Attributes of a 10GBASE SFP+ port
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ - SFP+ high-speed cable (1 m, 3 m, 5 m, 10 m), QSFP+ - 4*SFP+ high-speed cable (1 m, 3 m, 5 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the ET1D2S08SX1E and their attributes, see 10GE SFP+ Optical Modules, 10GE-CWDM SFP+ Optical Modules and 10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Attributes of a 10/100/1000BASE-T port
Attribute
Description
Connector type
RJ45
Standards compliance
IEEE 802.3ab
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Attributes of a 100/1000BASE-X port
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For optical modules supported by the ET1D2S08SX1E and their attributes, see FE SFP/eSFP Optical Modules, GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the ET1D2S08SX1E
Item
Description
Physical specifications
Dimensions (W x D x H): 394.7 mm x 426.8 mm x 35.1 mm (15.5 in. x 16.8 in. x 1.4 in.)
Weight: 2.84 kg (6.26 lb)
Maximum power consumption: 130 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
Operating relative humidity: 5% RH to 95% RH (noncondensing)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Storage relative humidity: 5% RH to 95% RH (noncondensing)
ET1D2S08SX1E FAQ
Q1: What are the core functions of this service board? How is cost-effectiveness and performance balanced?
A1: It includes 8 10GE SFP+ ports, supporting stable and high-performance forwarding, link aggregation, and QoS; core performance is uncompromising while controlling procurement costs, making it suitable for scenarios with limited budgets but a focus on efficiency.
Q2: Compared to ordinary 8-port high-performance 10G boards, what are its core advantages?
A2: The advantages are high-performance forwarding (low latency, no bottlenecks) + high cost-effectiveness. There's no need to pay for redundant functions, and it better meets the concurrent needs of multiple services than entry-level boards.
Q3: Does it require specific optical modules? Which core protocols does it support?
A3: It is compatible with Huawei standard SFP+ 10G optical modules (including models with different transmission distances); it supports IPv4/IPv6 dual-stack, LACP, and flow control, meeting the reliability and compatibility requirements of small and medium-sized networks.
Q4: How do I determine if this service board needs to be deployed? Is the installation complex?
A4: Recommended for small and medium-sized networks that require 8 10 Gigabit ports, have a limited budget, and prioritize stability and high performance; supports hot-swapping, installation requires no professional tools, automatically recognizes the slot, and is plug-and-play.
