Provides six 100GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Port of the LST7C06HX6E1
Attribute
Description
Connector type
QSFP28
Optical port attributes
Depend on the40GE QSFP+ Optical Modules, 100GE QSFP28 Optical Modules or QSFP+ or QSFP28 AOC cable used.
Applicable cable
QSFP+ optical module and LC optical fiber
QSFP+ optical module and MPO optical fiber (MPO-MPO or MPO-4*DLC optical fiber)
QSFP+ AOC cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP28 optical module and LC optical fiber
QSFP28 optical module and MPO optical fiber (MPO-MPO or MPO-4*DLC optical fiber)
QSFP28 AOC cable
Specifications of the LST7C06HX6E1
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.55 kg (7.83 lb)
Maximum power consumption: 189 W
LST7C06HX6E1 FAQ
Q1: What are the core advantages of this service board? How is the 100km long-distance transmission capability guaranteed?
A1: The core advantages are 100km repeater-free long-distance transmission, high reliability and low bit error rate, dual-rate compatibility, and green low power consumption; through optimized optical signal amplification, anti-interference design, and error correction mechanisms, the stability of ultra-long-distance transmission is ensured.
Q2: Which optical modules does it support? Can it be directly connected to existing 10G equipment?
A2: It supports Huawei standard QSFP+ 40G optical modules (SR4/LR4/ER4/ZR4) and QSFP+ 10G optical modules; 40G/10G dual-rate adaptive, it can be directly connected to existing 10G equipment without additional converter configuration.
Q3: How does its energy consumption and reliability compare to other 40G long-distance boards of the same level?
A3: Total power consumption ≤130W, 28% more energy efficient than comparable products; bit error rate as low as 10⁻¹³, supports link self-healing, superior reliability, suitable for mission-critical scenarios.
Q4: Suitable for which ultra-long-distance mission-critical scenarios? Is installation complex?
A4: Suitable for scenarios such as data center cross-regional core interconnection, carrier city backbone networks, and private networks in the financial/energy industries; supports hot-swapping, installation without downtime, automatic speed identification after insertion into the switch, and simple configuration.
