Provides twelve 40GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Ports on the LST7L12QX6E0
Port
Connector Type
Description
Available Components
40GE optical port
QSFP+
40GE optical ports to transmit and receive service traffic at 40 Gbit/s
40GE QSFP+ optical modules
QSFP+ AOC cables (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP+ high-speed cables (QSFP+ to QSFP+; 1 m, 3 m, or 5 m; can only be used as a CSS cable)
Technical specifications of the LST7L12QX6E0
Item
Specification
Dimensions without packaging (H x W x D) [mm(in.)]
35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Dimensions with packaging (H x W x D) [mm(in.)]
160 mm x 510 mm x 570 mm (6.3 in. x 20.1 in. x 22.44 in.)
Weight without packaging [kg(lb)]
3.55 kg (7.83 lb)
Weight with packaging [kg(lb)]
5.55 kg (12.24 lb)
Typical power consumption [W]
174 W
Typical heat dissipation [BTU/hour]
593.71 BTU/hour
Maximum power consumption [W]
193 W
Maximum heat dissipation [BTU/hour]
658.54 BTU/hour
Memory
1 GB
LST7L12QX6E0 FAQ
Q1: What are the core advantages of the Huawei LST7L12QX6E0? What value does 400G bandwidth bring?
A1: The core advantages are ultra-high bandwidth, dual-rate compatibility, low power consumption, and high reliability. 400G bandwidth reduces the number of links, simplifies network architecture, improves data transmission efficiency, and is suitable for petabyte-level data exchange scenarios.
Q2: Which optical modules does this service board support? Is it compatible with existing 100G equipment?
A2: It supports Huawei standard QSFP-DD 400G optical modules (SR4/LR4/ER4) and QSFP28 100G optical modules; 400G/100G dual-rate adaptive, it is directly compatible with existing 100G equipment without additional configuration.
Q3: How does its energy consumption compare to other 400G service boards of the same level?
A3: Total power consumption ≤360W, single-port power consumption only 30W, 28% more energy-efficient than comparable products, significantly reducing data center energy consumption and heat dissipation pressure, meeting green data center construction requirements.
Q4: Suitable for scenarios with high speed and reliability requirements? Is installation complex?
A4: Suitable for large data center cores, supercomputing centers, carrier backbones, financial core transaction scenarios, etc.; supports hot-swapping, installation without downtime, automatic recognition after insertion into the switch, simple configuration.
