Huawei OLT compatible EG8120L is an intelligent routing-type ONT that provides one GE port, one POTS port, and one FE port. The EG8120L features high-performance service forwarding capabilities to ensure excellent experiences with VoIP, Internet, and HD video services. Therefore, the EG8120L provides a perfect terminal solution and future-oriented service-supporting capabilities for networks.
The EG series optical network terminals (ONT) are user devices in FTTH (fiber to the home) solutions; it admit ultra-wideband access for residential or small business users (SOHO) using GPON technologies.
| Item | EG8120L |
| UNI | 1 GE + 1 FE+ 1 POTS |
| NNI | GPON |
| GPON Port | SC/APC or SC/UPC |
| Indicators | POWER/PON/LOS/LAN/TEL |
| Operating Temperature | 0°C to +40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100V to 240V AC, 50/60 Hz |
| System Power Supply | 11V to 14V DC, 1A |
| Static Power Consumption | 3.8W |
| Maximum Power Consumption | 4.9W |
| Weight | About 0.5g |
| Dimensions (H x W x D) | 30 mm x 115 mm x 94 mm |
