| Item | EG8141A5 |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Power consumption | Static power: 3.1W |
| Maximum power consumption: 7.15 W | |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 11–14 V DC, 1A | |
| Antenna gain | 5dBi |
| Network-side port | GPON (SC/UPC or SC/APC) |
| GPON port | Class B+ class |
| User-side port | 1*GE+3*FE+1*POTS+1*USB+2.4G wifi |
| Dimensions (length x width x height) | 152 mm x 105 mm x 30 mm |
| Weight | About 0.5 kg |
