Provides 4GE, 2USB and 1POTS, 2.4G&5G WiFi, internal antenna
Smart Wi-Fi coverage, SIP/H.248 auto-negotiation, Any port any service, Parental control, L2/L3(IPv4) forwarding: 1G uplink, 2G downlink
Scheduled Wi-Fi shutdown, Smart Wi-Fi sharing: Portal/802.1x authentication, SoftGRE-based sharing
IGMP v2/v3 proxy/snooping, MLD v1/v2 snooping
| Specification | |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Typical power consumption | 8 W |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 11–14 VDC, 2 A | |
| WLAN | 802.11ac |
| Support IPv4 or IPv6 | IPv4 and IPv6 |
| Network-side Port | GPON |
| User-side Ports | 1 x POTS + 4 x GE + 2.4G/5G Wi-Fi + 1 x USB |
| Indicators | POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB |
| Dimensions (length x width x height) |
265 mm x 176 mm x 82 mm |
| Weight | About 1.5 Kg |
FAQ
Q. Is this a Huawei brand product?
A. No, it's not a Huawei brand product. It's an OEM product, compatible with Huawei OLTs.
