Product Features
- Type: Box-shaped OLT (Optical Line Terminal).
- Ports: 8 GPON (Gigabit Passive Optical Network) ports for end-users.
- Uplinks: 4 GE/10GE (Gigabit/10 Gigabit Ethernet) upstream ports for connecting to the core network.
- Power: Supports dual AC/DC power supplies for redundancy.
- Design: Compact, low-density, 1U height, suitable for 19-inch racks or outdoor cabinets.
- Application: Ideal for fast fixed-mobile convergence (FMC), national broadband coverage, and enterprise campus networks where space or density is limited.
- Benefits: Simplifies network architecture, reduces operational expenses (OPEX), and offers flexible deployment.
Compatible ONTs
| Item |
Description |
| HG8310M |
1GE |
| EG8120L |
1GE+1FE+1TEL |
| HG8321R |
1GE+1FE+1TEL |
| HG8321V |
1GE+1FE+1TEL+CATV(12V) |
| HG8546M |
1GE+3FE+1USB+1TEL+WIFI(5dBi) |
| EG8141A5 |
1GE+3FE+1USB+1TEL+WIFI(5dBi) |
| EG8247H5 |
1GE+3FE+1USB+1TEL+CATV(5V)+WIFI(5dBi) |
| EG8143A5 |
1GE+3FE+1USB+1TEL+CATV(5V)+WIFI(5dBi) |
| HG8247H5 |
1GE+3FE+1TEL+1USB+CATV(12V)+WIFI(5dBi) |
| EG8145V5 |
4GE+1TEL+1USB+2.4/5G WIFI(5dBi) |
| EG8247W5 |
4GE+1TEL+2USB+CATV+2.4/5G WIFI(5dBi) 4Antennas |
| EG8147X6 |
4GE+USB+CATV+2.4/5G WIFI6 AX3000 (5dBi) |
| HG8245Q2 |
4GE+1TEL+2USB+2.4/5G WIFI |
| EG8145X6 |
4GE+1TEL+2USB+2.4/5G WIFI6 (5dBi) |
| HN8145X6 |
10GPON 4GE+1TEL+2USB+2.4/5G WIFI6 (5dBi) |
| HN8346V5 |
10GPON 4GE+1TEL+2USB+2.4/5G WIFI (5dBi) |
| K662C |
ONT/Edge Router with 1GE+3GE+2.4G/5GHz Wi-Fi6 |
Application Scenarios & Real-World Cases
1. Fixed Mobile Convergence (FMC)
Deployed in mobile cabinets by European operators to extend FTTH coverage to suburban areas, reducing deployment time by 40% while leveraging existing backhaul resources.
2. Rural Broadband Coverage
Used in Southeast Asian island nations to deliver high-speed internet to remote villages, paired with high-power GPON modules to cover 20km+ distances cost-effectively.
3. Enterprise All-Optical Campuses
Adopted by multinational corporations in the Middle East for campus networks, supporting 4K video conferencing, cloud services, and 2048+ concurrent device connections.
Downloadable resources
Technical Specifications
| Huawei MA5801-GP08-H3 OLT Datasheet |
| Switching capacity of the system |
110 Gbit/s |
| MAC address |
32768 |
| Access ONT |
1024 |
| IPv4 routing table |
8192 |
| IPv6 routing table |
4096 |
| ARP table |
16384 |
| Bit error rate (BER) in full load |
A BER smaller than 10 e-10 for a port that transmits data in full load |
| Upstream ports |
4 GE/10GE |
| Service ports |
8 GPON |
Dimensions
(W x D x H) (mm) |
1U height
Excluding mounting ears: 442 x 220 x 43.6
Including IEC mounting ears: 482.6 x 220 x 43.6
Including ETSI mounting ears: 531 x 220 x 43.6
|
| Maximum weight(including mounting brackets) |
5 kg |
| Maximum input current |
DC power supply: 6 A
AC power supply: 2.5 A
|
| Working voltage range |
DC power supply: –38.4 V to –72 V
AC power supply: 100 V to 240 V
|
| Ambient temperature |
–40°C to +65°C
The device can start up at a lowest temperature of –25°C.
NOTE: The +65°C temperature refers to the highest temperature measured at the air intake vent of a service subrack.
|
| Ambient humidity |
5% RH to 95% RH |
FAQ
Q: How many ONTs can the MA5801-GP08-H3 support?
A: It supports up to 1024 ONTs, making it suitable for medium-scale residential or enterprise deployments.
Q: What is the operating temperature range?
A: -40°C to +65°C (minimum startup temperature: -25°C), ideal for outdoor and extreme environment deployment.
Q: What warranty does MF-Telecom provide?
A: Global warranty on genuine Huawei hardware, with technical support services available worldwide.
Q2: What power supply options are available?
A2: The chassis supports 2 pluggable power modules, with AC or DC options for dual backup.
Q: What is the after-sales service period?
A: We provide a one-year warranty and technical support.
