| Item | HG8546M 5dBi |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Pressure environment: 0 to 106 kPa | |
| Altitude: 3000 m | |
| Power consumption | Static power: 6 W |
| Maximum power consumption: 14 W | |
| Power specifications | Power adapter input: 180 to 240 V AC, 50–60 Hz |
| System power supply: 11–14 VDC, 1 A | |
| Security | MAC/IP/URL Filter |
| GPON port | B+ class Module |
| Network-side port | GPON(SC/UPC) |
| Antenna gain | 5dBi |
| Dimensions (length x width x height) | 176 mm x 138.5 mm x 28 mm |
| Weight | About 0.5 Kg |
