| Item | Parameters |
| NNI | XGPON |
| UNI | 4*GE+1*POTS+1*USB2.0+1*downlink optical port+2.4GHz&5GHz Wi-Fi |
|
Fiber optic port |
Connect to the home optical cable and support XG-PON asymmetric uplink access |
|
XG-PON Interface |
• XG-PON: Class N1/N2a |
|
Wi-Fi |
• IEEE 802.11 b/g/n/ax(2.4GHz) |
| Ethernet port | • VLAN Tag/Tag stripping based on Ethernet port • 1:1 VLAN/N:1 VLAN/VLAN transparent transmission • QinQ VLAN • MAC address restriction • MAC address learning • Support 10/100/1000Mbps adaptive |
| Downstream optical interface | • P2MP optical interface • Plug and play from FTTR |
| USB port | • USB 2.0 |
| Telephone port | • Maximum number of ports connected to phones: 4 • G.711A/u, G.729a/b, G.722 codecs • Support T.30/T.38/G.711 fax • DTMF • Emergency call (SIP protocol) |
| Function | Work as the main FTTR to realize the full optical home |
| O&M | OMCI/OAM/Web UI/TR069 Variable length OMCI |
| Dimensions | 157mm x 250mm x 30mm (without base) |
| (length x width x height) | |
| Weight | About 600g |
| Working environment | Operating temperature: 0°C ~ +40°C |
| Environment humidity: 5% to 95% (noncondensing) | |
| Storage | 256MB Flash，512MB RAM |
| Max. power consumption | 20 W |
| Power specifications | Power adapter input: 170~240V AC, 50/60Hz |
| System power supply: 12V DC, 2 A |
