Provides twenty-four 10M/100M/1000M Ethernet electrical ports for data transmission and switching.
Energy Efficient Ethernet (EEE)
The EEE mode can dynamically adjust power consumption based on network traffic volume.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0DG24TFA00 is hot swappable.
Ports on the LE0DG24TFA00
Attribute
Description
Connector type
RJ45
Standards compliance
IEEE802.3ab and IEEE802.3az
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0DG24TFA00
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.20 kg (4.85 lb)
Maximum power consumption: 32 W
LE0DG24TFA00 FAQ
Q1: What are the port types, speeds, and transmission distances of this interface card? Does it support hot-swapping?
A1: It contains 24 100/1000M Gigabit Ethernet ports (RJ45); transmission distance ≤100m (direct cable connection); supports hot-swapping, ensuring uninterrupted service during maintenance.
Q2: What are the core advantages compared to a 48-port card? Which Huawei switches is it compatible with?
A2: The number of ports is precisely matched to small and medium-sized scenarios, avoiding resource waste; low power consumption is more suitable for environments with limited power supply; fully compatible with the entire Huawei S9300 chassis series.
Q3: Does the 85W low power consumption have a real energy-saving effect? What specifications of network cables does it support?
A3: Annual electricity costs are 30% lower than similar high-power cards, with significant long-term energy-saving advantages; supports Cat5e and higher specification network cables, meeting conventional cabling needs.
