Provides twelve 10GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0DX12XSA00 is hot swappable.
Ports on the LE0DX12XSA00
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ to SFP+ high-speed cable (1 m or 10 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the LE0DX12XSA00 and their attributes, see 10GE SFP+ Optical Modules (OSXD22N00 not supported), 10GE-CWDM SFP+ Optical Modules and 10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0DX12XSA00
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.30 kg (5.07 lb)
Maximum power consumption: 85 W
LE0DX12XSA00 FAQ
Q1: What is the maximum single-port speed and transmission distance of the Huawei LE0DX12XSA00 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 1000Mbps (Gigabit), maximum transmission distance is 10km (single-mode) / 0.5km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with the S5735-S switch (requires upgrading to the latest system version); a single S7706 switch supports a maximum of 8 cards, providing 96 Gigabit ports, meeting the expansion needs of small networks with multiple nodes.
Q3: Compared to 8-port/16-port Gigabit cards and long-distance Gigabit cards, what are the core advantages of the LE0DX12XSA00?
A3: 50% more ports than an 8-port card, no need to add extra slots; 20% lower cost than a 16-port card, no port redundancy; 25% lower cost than a long-range card, best cost performance for short-range essential scenarios, suitable for small networks.
