Provides forty 1000M/10GE BASE-X optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0DX40SFC00 is hot swappable.
Ports on the LE0DX40SFC00
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used. For the optical modules supported by the LE0DX40SFC00 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0DX40SFC00
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.90 kg (6.39 lb)
Maximum power consumption: 183 W
LE0DX40SFC00 FAQ
Q1: What is the maximum single-port speed and transmission distance of the Huawei LE0DX40SFC00 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 1000Mbps (Gigabit), maximum transmission distance is 10km (single-mode) / 0.5km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with the S5735-S switch (requires upgrading to the latest system version); a single S7706 switch supports up to 6 cards, providing 240 Gigabit ports, meeting the large-scale expansion needs of small and medium-sized networks.
Q3: Compared to 24-port Gigabit cards and long-distance Gigabit cards, what are the core advantages of the LE0DX40SFC00?
A3: Offers 67% higher density than 24-port cards, while reducing slot usage by 40% for the same requirements; 25% lower cost than long-distance gigabit cards, with no functional redundancy; and provides better cost-effectiveness for gigabit expansion in small and medium-sized networks.
