Provides data transmission and switching on sixteen GE optical ports and eight combo ports. The combo ports can be configured as either optical ports or electrical ports.
NOTE:
A maximum of twenty-four ports, that is, sixteen GE optical ports and eight combo ports, can work at the same time on the LE0MG24CA.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0MG24CA is hot swappable.
Ports on the LE0MG24CA
Attribute
Description
Connector type
RJ45
Standards compliance
IEEE 802.3ab
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0MG24CA
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.26 kg (5.86 lb)
Maximum power consumption: 67 W
LE0MG24CA FAQ
Q1: What are the port types, speeds, and transmission distances of this interface card? Does it support hot-swapping?
A1: It includes 24 Gigabit (100/1000M) optical ports (SFP); transmission distance 0.5km-80km (depending on the SFP optical module); supports hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Compared to a 48-port Gigabit optical port card, what are its core advantages? Which Huawei switches is it compatible with?
A2: The number of ports is precisely matched to small and medium-sized scenarios, avoiding resource waste; low power consumption is more suitable for environments with limited power supply; fully compatible with the entire Huawei S9300 series chassis.
Q3: Does the 90W low power consumption have a real energy-saving effect? Which types of SFP optical modules does it support?
A3: Annual electricity costs are 35% lower than similar high-power cards, offering significant long-term advantages; supports a full range of multimode/single-mode, short-distance/long-distance SFP optical modules, ensuring strong compatibility.
