Provides twenty-four GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0MG24SA is hot swappable.
Ports on the LE0MG24SA
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For details about optical modules supported by the LE0MG24SA and their attributes, see FE SFP/eSFP Optical Modules, GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0MG24SA
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.22 kg (4.89 lb)
Maximum power consumption: 45 W
LE0MG24SA FAQ
Q1: What are the port types, speeds, and transmission distances of this interface card? Does it support hot-swapping?
A1: It includes 24 Gigabit (100/1000M) optical ports (SFP); transmission distance 0.5km-40km (depending on the SFP optical module); supports hot-swapping, ensuring uninterrupted access services during maintenance.
Q2: Compared to a 48-port Gigabit optical port card, what are its core advantages? Which Huawei switches is it compatible with?
A2: The number of ports precisely matches small to medium-sized needs, avoiding resource waste; low power consumption is more suitable for scenarios with limited power supply; fully compatible with the entire Huawei S9300 series chassis.
Q3: Does the 85W low power consumption have a real energy-saving effect? Which types of SFP optical modules does it support?
A3: Annual electricity costs are 37% lower than similar high-power cards, offering significant long-term advantages; supports mainstream multimode/single-mode, short-distance/medium-to-long-distance SFP optical modules, ensuring strong compatibility.
