Provides two 10GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0MX2UXC is hot swappable.
Ports on the LE0MX2UXC
Attribute
Description
Connector type
XFP
Optical port attributes
Depend on the XFP optical module used.
For details about the optical modules supported by the LE0MX2UXC and their attributes, see 10GE XFP Optical Modules, 10GE-CWDM XFP Optical Modules, and 10GE-DWDM XFP Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0MX2UXC
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.26 kg (4.98 lb)
Maximum power consumption: 61 W
LE0MX2UXC FAQ
Q1: What is the maximum single-port speed and transmission distance of the Huawei LE0MX2UXC interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps (10 Gigabit), maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S7706 switch supports a maximum of 16 cards, providing 32 10 Gigabit ports, meeting the multi-point-to-point 10 Gigabit expansion needs of small networks.
Q3: Compared to 4-port 10 Gigabit cards and ordinary 2-port 10 Gigabit cards, what are the core advantages of the LE0MX2UXC?
A3: 30% cheaper than a 4-port 10 Gigabit card, with no port redundancy; 50% smaller than a regular 2-port 10 Gigabit card, making it more suitable for confined spaces; optimized for long distances, providing better point-to-point transmission stability, making it suitable for core links.
