Provides four 10GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0MX4UXC is hot swappable.
Ports on the LE0MX4UXC
Attribute
Description
Connector type
XFP
Optical port attributes
Depend on the XFP optical module used.
For details about the optical modules supported by the LE0MX4UXC and their attributes, see 10GE XFP Optical Modules, 10GE-CWDM XFP Optical Modules, and 10GE-DWDM XFP Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0MX4UXC
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.28 kg (5.03 lb)
Maximum power consumption: 75 W
LE0MX4UXC FAQ
Q1: What is the maximum single-port speed and transmission distance of the Huawei LE0MX4UXC interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps (10 Gigabit), maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S7706 switch supports a maximum of 12 cards, providing 48 10 Gigabit ports, meeting the 10 Gigabit expansion needs of multi-core nodes in small and medium-sized networks.
Q3: Compared to 8-port 10 Gigabit cards and ordinary 4-port 10 Gigabit cards, what are the core advantages of the LE0MX4UXC?
A3: 35% lower cost than an 8-port 10 Gigabit card, with no port redundancy; 30% smaller size than a regular 4-port 10 Gigabit card, with higher integration; adaptable to both long-range and short-range scenarios, offering strong deployment flexibility and suitable for upgrading small and medium-sized networks to 10 Gigabit speeds.
