Provides two 100GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Ports on the LE1D2C02FEE0
Attribute
Description
Connector type
CFP
Optical port attributes
Depend on the 40GE CFP Optical Modules and 100GE CFP Optical Modules used
Applicable cable
CFP optical module and LC optical fiber
CFP optical module and MPO optical fiber (MPO-MPO, MPO-2*MPO, or MPO-10*DLC optical fiber)
Specifications of the LE1D2C02FEE0
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 4.20 kg (9.26 lb)
Maximum power consumption: 339 W
Environment specifications
Operating temperature:
When the card is used in an S9303, S9306 or S9312 chassis: 0°C to 40°C (32°F to 104°F), when the ambient temperature exceeds 40°C (104°F), the bandwidth on port 1 will decrease to 60 Gbit/s. When the ambient temperature falls within the range of 0°C to 40°C (32°F to 104°F), the bandwidth on port 1 will restore to 100 Gbit/s.
When the card is used in an S9300E or S9310 chassis: 0°C to 45°C (32°F to 113°F)
LE1D2C02FEE0 FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE1D2C02FEE0 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 100Gbps, maximum transmission distance is 10km (single-mode) / 2km (multi-mode); supports QSFP28 module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with S5735-S switches; a single S7706 switch supports a maximum of 8 cards, providing 16 100G ports to meet the needs of multi-site distributed upgrades.
Q3: What are the advantages of the LE1D2C02FEE0 compared to a 4-port 100G interface card?
A3: Suitable for scenarios requiring 1-2 100G ports, with a procurement cost 50% lower; more compact size, adaptable to the limited space of small and medium-sized data centers, and easier to install.
