Provides four 100GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Ports on the LE1D2C04HX2S
Attribute
Description
Connector type
QSFP28
Optical port attributes
Depend on the QSFP28 high-speed cable (1 m, 3 m, 5 m), QSFP+ high-speed cable (1 m, 3 m, 5 m), 40GE QSFP+ Optical Modules, 100GE QSFP28 Optical Modules or QSFP+ or QSFP28 AOC cable used.
Applicable cable
QSFP+ optical module and LC optical fiber
QSFP+ optical module and MPO optical fiber (MPO to MPO or MPO to 4*DLC optical fiber)
QSFP+ high-speed copper cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP+ AOC cable (QSFP+ to QSFP+ or QSFP+ to 4*SFP+)
QSFP28 optical module and LC optical fiber
QSFP28 optical module and MPO optical fiber (MPO to MPO)
QSFP28 high-speed copper cable
QSFP28 AOC cable
Specifications of the LE1D2C04HX2S
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.05 kg (6.72 lb)
Maximum power consumption: 154.7 W
LE1D2C04HX2S FAQ
Q1: What is the maximum single-port speed of the Huawei LE1D2C04HX2S interface card? Does it support hot-swapping?
A1: The maximum single-port speed is 100Gbps. It supports QSFP28 module hot-swapping; module replacement does not require restarting the switch, ensuring uninterrupted service.
Q2: Is this interface card compatible with the Huawei S5735-S switch? What is the maximum number of cards supported by a single S7712 unit?
A2: Fully compatible with the S5735-S switch (system version upgrade required); a single S7712 unit supports a maximum of 12 cards, providing 48 100G ports, meeting the needs of large-scale phased expansion.
Q3: What are the advantages of the LE1D2C04HX2S compared to an 8-port 100G interface card (such as the Huawei LE2D2C08HX2H)?
A3: Suitable for scenarios with low demand for 100G ports or for phased expansion, with a procurement cost 40% lower; each port is independently designed, so failure does not affect other services, and maintenance is more flexible.
