Provides four 10G Ethernet optical ports, sixteen 100/1000M Ethernet optical ports, and eight 10/100/1000M combo ports for data access and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Software feature
LAN/WAN switchover
Hot swapping
The LE1D2S04SX1E is hot swappable.
Ports on the LE1D2S04SX1E
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ to SFP+ high-speed cable (1 m, 3 m, 5 m, 10 m), QSFP+ to 4*SFP+ high-speed cable (1 m, 3 m, 5 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the LE1D2S04SX1E and their attributes, see 10GE SFP+ Optical Modules, 10GE-CWDM SFP+ Optical Modules and10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1D2S04SX1E
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.88 kg (6.35 lb)
Maximum power consumption: 130 W
LE1D2S04SX1E FAQ
Q1: What are the port combinations, speeds, and transmission distances of the Huawei LE1D2S04SX1E? Does it support hot-swapping?
A1: It includes 4 x 10Gbps ports + 16 x 1000Mbps Gigabit ports + 8 x 10/100/1000M Combo ports; the 10Gbps ports have a maximum transmission range of 10km (single-mode) / 0.3km (multi-mode), and the low-speed ports support the corresponding optical module transmission distances; it supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrading to the latest system version); a single S7706 unit supports a maximum of 16 cards, providing 64 x 10Gbps ports + 384 low-speed ports, meeting the large-scale expansion needs of small and micro enterprises.
Q3: What are the core advantages compared to a regular 4-port 10 Gigabit Ethernet card and a standalone low-speed card?
A3: It has 24 more low-speed ports than a regular 10 Gigabit Ethernet card, eliminating the need for additional card deployments; it offers higher integration than standalone multi-card setups, reducing slot usage by 75%; it supports multiple speeds across all scenarios, making its cost-effectiveness far superior to standalone device combinations.
