Provides four 10GE optical ports and forty-four GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE1D2S04SX5E is hot swappable.
Ports on the LE1D2S04SX5E
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used.
For the optical modules supported by the LE1D2S04SX5E and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1D2S04SX5E
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.1 kg (6.83 lb)
Maximum power consumption: 124 W
LE1D2S04SX5E FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE1D2S04SX5E interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps (10 Gigabit), maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with Huawei S5735-S switches? How many cards can a single S7706 switch support at most?
A2: Fully compatible with S5735-S switches (requires upgrade to the latest system version); a single S7706 switch supports a maximum of 12 cards, providing 48 10 Gigabit ports, meeting the multi-core node expansion needs of small and medium-sized enterprises.
Q3: Compared to 8-port 10 Gigabit cards and ordinary 4-port 10 Gigabit cards, what are the core advantages of the LE1D2S04SX5E?
A3: 30% lower cost than an 8-port 10 Gigabit card, with no port redundancy; 15% higher reliability than a regular 4-port 10 Gigabit card, with stronger adaptability to enterprise-level scenarios; streamlined design saves data center space and is suitable for the actual needs of small and medium-sized enterprises.
