Provides eight 10GBASE-X ports and eight 10/100/1000M combo ports for data access and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE1D2S08SX1E is hot swappable.
Ports on the LE1D2S08SX1E
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ to SFP+ high-speed cable (1 m, 3 m, 5 m, 10 m), QSFP+ to 4*SFP+ high-speed cable (1 m, 3 m, 5 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the LE1D2S08SX1E and their attributes, see 10GE SFP+ Optical Modules, 10GE-CWDM SFP+ Optical Modules and 10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1D2S08SX1E
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.84 kg (6.26 lb)
Maximum power consumption: 130 W
LE1D2S08SX1E FAQ
Q1: What are the port combinations, speeds, and transmission distances of the Huawei LE1D2S08SX1E? Does it support hot-swapping?
A1: It includes 8 x 10Gbps ports + 8 x 1000Mbps ports; the 10Gbps ports have a maximum transmission range of 10km (single-mode) / 0.3km (multi-mode), and the Gigabit ports support the corresponding optical module transmission distances; it supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrading to the latest system version); a single S7706 unit supports a maximum of 12 cards, providing 96 x 10Gbps ports + 96 x Gigabitbps ports, meeting the large-scale expansion needs of small and medium-sized enterprises.
Q3: What are the core advantages compared to ordinary 8-port x 10Gbps cards and independent Gigabitbps cards?
A3: It has 8 more gigabit ports than a regular 10-gigabit card, eliminating the need for additional gigabit cards; it has higher integration than a standalone dual-card system, reducing slot usage by 50%; its streamlined and enhanced design balances stability and cost-effectiveness, making it suitable for the budgets and scenarios of small and medium-sized enterprises.
