Provides eight 10GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
Supported
Ports on the LE1D2X08SSC0
Attribute
Description
Connector type
SFP
Optical attributes
Depend on the SFP optical module used.
For the optical modules supported by the LE1D2X08SSC0 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1D2X08SSC0
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.74 kg (6.04 lb)
Maximum power consumption: 109 W
LE1D2X08SSC0 FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE1D2X08SSC0 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps, maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S7706 switch support at most?
A2: Fully compatible with the S5735-S switch (requires upgrading to the latest system version); a single S7706 switch supports a maximum of 10 cards, providing 80 10G ports, meeting the multi-node expansion needs of small networks.
Q3: Compared to 12-port/16-port 10G cards and long-range 8-port 10G cards, what are the core advantages of the LE1D2X08SSC0?
A3: 25% lower cost than multi-port cards, no port redundancy; 25%+ lower cost and 15% lower power consumption than long-range cards, making it more cost-effective for short-range scenarios; lightweight design saves data center space and reduces maintenance difficulty.
