Provides twenty-four 10GE optical ports and twenty-four GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE1DAS24SX2S is hot swappable.
Ports on the LE1DAS24SX2S
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used. For the SFP optical modules supported by the LE1DAS24SX2S and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1DAS24SX2S
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.4 kg (7.50 lb)
Maximum power consumption: 237.9 W
Environment specifications
Operating temperature: 0°C to 45°C (32°F to 113°F)
NOTE:
When the card is installed in an S9303, S9306, or S9312 switch and uses 10G SFP+ optical modules with the maximum transmission distance of 10 km, its operating temperature is 0°C to 42°C (32°F to 107.6°F).
LE1DAS24SX2S FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE1DAS24SX2S interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps (10 Gigabit), maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S12708 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S12708 unit supports up to 8 cards, providing 192 10 Gigabit ports, meeting the ultra-high-density expansion needs of medium and large enterprises.
Q3: Compared to 12-port/16-port 10 Gigabit cards and dedicated high-density cards, what are the core advantages of the LE1DAS24SX2S?
A3: Offers twice the density of low-density cards, resulting in higher slot utilization; more versatile than dedicated cards, allowing enterprises to expand capacity across multiple scenarios without replacing cards; full compatibility and high cost-effectiveness reduce overall procurement and maintenance costs.
