Provides eight 10GE BASE-X optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE2D2X08SED5 is hot swappable.
Ports on the LE2D2X08SED5
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP+ to SFP+ high-speed cable (1 m, 3 m, 5 m, 10 m), QSFP+ to 4*SFP+ high-speed cable (1 m, 3 m, 5 m), SFP+ optical module, or SFP+ optical cable used.
For the optical modules supported by the LE2D2X08SED5, see 10GE SFP+ Optical Modules, 10GE-CWDM SFP+ Optical Modules and 10GE-DWDM SFP+ Optical Modules.
Standards compliance
IEEE 802.3ae
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE2D2X08SED5
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.50 kg (5.51 lb)
Maximum power consumption: 198.1 W
LE2D2X08SED5 FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE2D2X08SED5 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps, maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S12712 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S12712 unit supports a maximum of 12 cards, providing 96 10G ports, meeting the expansion needs of multi-core nodes in small and medium-sized networks.
Q3: Compared to 12-port/16-port 10G cards and ordinary long-distance 8-port 10G cards, what are the core advantages of the LE2D2X08SED5?
A3: 25% lower cost than multi-port cards, no port redundancy; 20% better anti-interference capability than ordinary long-distance cards, with superior stability in long-distance scenarios; multi-series compatibility + dual-scenario adaptation, strong deployment flexibility.
