Provides forty-eight 1000M/10G BASE-X ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE2D2X48SEC0 is hot swappable.
Ports on the LE2D2X48SEC0
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used. For the SFP optical modules supported by the LE2D2X48SEC0 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE2D2X48SEC0
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.42 kg (7.54 lb)
Maximum power consumption: 300 W
LE2D2X48SEC0 FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LE2D2X48SEC0 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps, maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S12712 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S12712 unit supports a maximum of 8 cards, providing 384 10G ports, meeting the needs of ultra-large short-distance expansion.
Q3: Compared to long-distance 10G high-density cards and 24-port 10G cards, what are the core advantages of the LE2D2X48SEC0?
A3: 30% lower cost than long-range high-density cards, with no functional redundancy; double the density of 24-port cards, with 50% less slot usage; higher cost-effectiveness in short-range scenarios, with significant cost advantages for batch deployment.
