Provides twenty-four 10GE optical ports and twenty-four GE optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LST3X24BX6E0 is hot swappable.
Ports on the LST3X24BX6E0
Attribute
Description
Connector type
SFP+
Optical port attributes
Depend on the SFP optical module used.
For the optical modules supported by the LST3X24BX6E0 and their attributes, see GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LST3X24BX6E0
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.2 kg (7.05 lb)
Maximum power consumption: 159 W
LST3X24BX6E0 FAQ
Q1: What are the maximum single-port speed and transmission distance of the Huawei LST3X24BX6E0 interface card? Does it support hot-swapping?
A1: Maximum single-port speed is 10Gbps (10 Gigabit), maximum transmission distance is 10km (single-mode) / 0.3km (multi-mode); supports SFP+ module hot-swapping, ensuring uninterrupted maintenance of core services.
Q2: Is this interface card compatible with the Huawei S5735-S switch? How many cards can a single S12712 unit support at most?
A2: Fully compatible with the S5735-S switch (requires upgrade to the latest system version); a single S12712 unit supports up to 10 cards, providing 240 10 Gigabit ports, meeting the ultra-high-density expansion needs of medium and large enterprises.
Q3: Compared to 12-port/16-port 10 Gigabit cards and ordinary high-density 10 Gigabit cards, what are the core advantages of the LST3X24BX6E0?
A3: 2 times higher density than low-density cards, resulting in higher slot utilization; 20% higher reliability than ordinary high-density cards, with stronger anti-interference capabilities; full series compatibility + dual-scenario coverage, making enterprise expansion more flexible and reducing overall costs.
