Provides forty-eight 100M/1000M optical ports for data transmission and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE0DG48SBC00 is hot swappable.
Ports on the LE0DG48SBC00
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For details about optical modules supported by the LE0DG48SBC00 and their attributes, see FE SFP/eSFP Optical Modules, GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE0DG48SBC00
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 2.90 kg (6.39 lb) (excluding the optical module)
Maximum power consumption: 185 W
LE0DG48SBC00 FAQ
Q1: What are the port types, speeds, and transmission distances of the Huawei LE0DG48SBC00? Does it support hot-swapping?
A1: It contains 48 100/1000M gigabit optical ports (SFP); transmission distance depends on the SFP optical module (0.22km-100km); it supports hot-swapping of SFP modules, ensuring uninterrupted service during maintenance.
Q2: Is this interface card compatible with the Huawei S9303 chassis? What is the maximum number of S9312 cards supported by a single unit?
A2: Fully compatible with the entire S9300 series chassis; a single S9312 unit supports a maximum of 12 cards, providing 576 gigabit optical ports to meet ultra-large-scale aggregation needs.
Q3: What are the core advantages compared to a 24-port gigabit optical port card? Does it support CWDM/DWDM optical modules?
A3: Density increased by 100%, slot occupancy reduced by 50%; supports 100/1000M multi-rate compatibility; supports GE-CWDM/DWDM SFP optical modules, enabling ultra-long-distance transmission of 80km-120km.
