Provides forty-eight GE optical ports for data access and switching.
Distributed forwarding
Performs concurrent data forwarding using a distributed data plane.
Hot swapping
The LE1D2G48SX5E is hot swappable.
Ports on the LE1D2G48SX5E
Attribute
Description
Connector type
SFP
Optical port attributes
Depend on the SFP optical module used.
For optical modules supported by the LE1D2G48SX5E and their attributes, see FE SFP/eSFP Optical Modules, GE eSFP Optical Modules, GE-CWDM eSFP Optical Modules, and GE-DWDM eSFP Optical Modules.
Standards compliance
IEEE 802.3z
Frame format
Ethernet_II, Ethernet_SAP, Ethernet_SNAP
Network protocol
IP
Specifications of the LE1D2G48SX5E
Item
Description
Physical specifications
Dimensions (H x W x D): 35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.)
Weight: 3.1 kg (6.83 lb)
Maximum power consumption: 110 W
LE1D2G48SX5E FAQ
Q1: What are the port types, speeds, and transmission distances of the Huawei LE1D2G48SX5E? Does it support hot-swapping?
A1: It contains 48 100/1000M gigabit optical ports (SFP); transmission distance depends on the SFP optical module (0.22km-100km); it supports hot-swapping of SFP modules, ensuring uninterrupted service during maintenance.
Q2: What are the advantages of this interface card's 110W low power consumption? Is it compatible with the S9303 chassis?
A2: 110W power consumption is 30% lower than similar high-density cards, making it suitable for power-constrained scenarios and reducing annual electricity costs by 40%; it is fully compatible with the entire S9300 series chassis, requiring no additional upgrades.
Q3: What are the core advantages compared to a 24-port gigabit optical port card? Does it support CWDM/DWDM optical modules?
A3: Doubled density, 50% reduction in slot usage; supports low power consumption and multi-rate compatibility; supports GE-CWDM/DWDM SFP optical modules, enabling ultra-long-distance transmission of 80km-120km.
